API “The BOX” Operator’s Manual

The summing input MUTE and SOLO switches are located just above the fader.

NOTE: The SAFE switch is located below the pan-pot.

Refer to section 9.0 Solo Master for more information regarding the solo system.

MUTE: Cuts the channel output

• Located post-fader in the signal flow

• Illuminates in red when engaged

• Activates on release

SOLO: Activates the current solo function on that channel

• PFL, AFL, or solo-in-place (PFL is default)

• Can be cleared by pressing the SOLO CLEAR switch

• Illuminates in orange when engaged

SAFE (solo safe): Activates the solo-safe function on that channel

• SAFE prevents muting when Solo-In-Place is active and another

channel is soloed.

• Illuminates when engaged

SUMMING FADER: Primary output level control

• 100mm full-size audio-taper fader

• -∞dB to +12dB range

• 0dB is unity gain

• White fader cap
